A GE Monogram dishwasher can display C1, C3, C4, C5, C7, FTD, F56, LEAK DETECTED, 999, H2O, or PrS when the control detects a problem with draining, filling, temperature sensing, leak protection, or water-pressure monitoring. These messages narrow the search to an affected system, but they do not always identify one failed component.

Code availability and meaning can also vary by model. Homeowners should record the complete display and the dishwasher’s model number before clearing the message or disconnecting power.

Drain Codes C1, C3, FTD, and F56

C1 Error Code

The C1 error code means the drain pump has operated for more than two minutes without completing the expected pump-out. GE recommends checking the air gap, drain hose, and garbage disposal for restrictions or incorrect routing. A clogged disposal or slow-draining sink can also interfere with dishwasher drainage.

C3 Error Code

C3 means the dishwasher did not drain. GE advises disconnecting power at the circuit breaker for approximately 30 seconds and then restoring it. If standing water remains or the code returns, the drain pump, hose, wiring, or electronic controls may require professional diagnosis.

FTD and F56 Error Codes

The FTD and F56 codes also indicate a failure to drain. Check for a kinked drain hose, clogged air gap, debris in the accessible filter or sump area, and an obstructed garbage-disposal connection. Do not continue starting new cycles while water remains in the tub because additional filling may increase the risk of overflow.

Water-Level Codes C4 and C5

C4 Error Code

The C4 code can appear when the dishwasher fills twice following a power interruption, the float switch is stuck or has failed, or the drain or sump is clogged. GE recommends pressing Start and then Cancel/Reset, gently checking the float cover for free movement, and inspecting the sump area for visible debris.

C5 Error Code

The C5 error code means the pump-out period was shorter than expected. Confirm that the dishwasher’s water supply is fully open, retry the cycle, and check whether the float cover is stuck.

If C4 or C5 keeps returning, the problem may involve water-level sensing, drainage, water-fill control, or related wiring rather than a simple obstruction.

C7: Water-Temperature Sensor Circuit Fault

The C7 code indicates that the dishwasher’s water-temperature sensor circuit is not operating correctly. GE recommends switching power off at the circuit breaker for approximately 30 seconds and then restarting the appliance.

A recurring C7 message requires model-specific testing because the temperature sensor, wiring, connectors, or electronic control may be responsible. The dishwasher may interrupt the cycle, stop heating normally, or fail to regulate wash-water temperature as expected.

Homeowners should not remove access panels or attempt to test heater and sensor wiring while the appliance is connected to power.

H2O and PrS Water-Monitoring Alerts

H2O Error Code

The H2O code means the dishwasher is receiving too little water or no water during the timed filling period. Confirm that the hot-water shutoff valve under the sink is fully open, the inlet hose is not kinked, and the dishwasher is level. Plumbing work or a recently closed supply valve can also trigger the message.

GE notes that H2O appearing only during a 1-Hour Wash cycle should be referred for service. When it appears during another wash program, homeowners should first inspect the inlet hose and water supply.

PrS Error Code

The PrS code means the pressure sensor is sending an invalid signal to the electronic control. The dishwasher may refuse to start or cancel the selected cycle. GE identifies the sensor or its wiring harness as likely areas requiring professional inspection.

LEAK DETECTED and the Model-Dependent 999 Code

LEAK DETECTED Message

A LEAK DETECTED message means the dishwasher’s protection system has sensed a possible water leak and canceled the cycle. Stop using the machine, check the surrounding floor and cabinets, and turn off the water supply if leakage is visible. GE recommends service instead of repeated resets.

999 Error Code

The meaning of 999 depends on the dishwasher model. On appliances equipped with the Floor Protect with Alert feature, it can indicate a possible leak and prevent the dishwasher from starting.

On certain compact models, including Monogram ZDT165 dishwashers, GE provides a control-reset procedure. Press and hold Cycle Select and Start together for five seconds, wait for 999 to disappear, and then press any button to finish the reset. Because the same code can have a different meaning on another model, always verify the exact model before following this procedure.

GE Monogram Dishwasher Service in San Diego

A one-time message may clear after an accessible blockage is removed, the water valve is opened, or the control is reset once. Professional diagnosis is appropriate when the code returns, water remains in the tub, the dishwasher will not fill, a leak warning appears, or the appliance repeatedly cancels its cycle.

Reset Appliance Repair provides GE Monogram dishwasher diagnostics in San Diego for drain failures, filling problems, float and pressure-sensor faults, temperature-sensing errors, and leak-protection alerts.
